    Chair Accumulator Blow Molding Equipment 160l Blow Moulding Machine For Plastic Bottle

    Ask Lasest Price
    Brand Name : SHUANGLI
    Model Number : SLBC-110
    Certification : ISO, CE
    Price : Price negotiation.
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set per month
    Delivery Time : 20 woking day
    • Product Details
    • Company Profile

    Chair Accumulator Blow Molding Equipment 160l Blow Moulding Machine For Plastic Bottle

    1 Die Head Accmulator Type Single Station Plastic Blow Molding Machine For Plastic Chair Toys


    SLBC series: (German model)


    1: the whole system is equipped with safety protection grating, to ensure the safety of the production process.


    2.The maintenance of the pneumatic system consists of the following aspects:

    (1) Ensure that clean compressed air is supplied to the pneumatic system.

    (2) Ensure that the air used to drive the cylinder contains an appropriate amount of lubricant.

    (3) Ensure that the pneumatic system has a suitable working pressure and that the pneumatic device has a suitable speed of movement.

    (4) Ensure the tightness of the pneumatic system.


    .


    SPECIFICATIONSLBC-110
    MATERIAL PE,PP,EVA,ABS,PS
    MAX CONTAINER CAPACITYL160
    OUPUT(DRY CYCLE)PC/HR360
    MACHINE DIMENSION (LxWxH )MM7500x3600x5800
    TOTAL WEIGHTTON20T
    CLAMPING UNIT
    CLAMPING FORCEKN680
    PLATEN OPENING STROKEMM600-1400
    PLATEN SIZE(WxH)MM1400x1600
    MAX MOULD SIZE(WxH)MM1200x1900
    MOLD THICKNESSMM610-880
    EXTRUDER UNIT
    SCREW DIAMETERMM110
    SCREW L/D RATIOL/D25
    MELTING CAPACITYKG/HR220
    BARREL HEATING POWERKW36
    NUMBER OF HEATING ZONEZONE6
    EXTRUDER MOTOR RATED POWERKW75
    DIE HEAD
    NUMBER OF DIE HEATING ZONEZONE5
    POWER OF DIE HEATINGKW35
    MAX DIE-PIN DIAMETERMM550
    POWER
    MAX DRIVE POWERKW120
    TOTAL POWERKW130
    FAN POWER OF SCREWKW4.8
    AIR PRESSUREMPA0.8-1.2
    AIR CONSUMPTIONM3/MIN0.8
    AVERAGE ENERGY CONSUMPTIONKW56
    ACCUMULATOR CAPACITYL20
