    5l EVA Fully Automatic Blow Moulding Machine ABS Bottle Water

    Ask Lasest Price
    Brand Name : SHUANGLI
    Model Number : SLBU-65
    Certification : ISO, CE
    Price : Price negotiation.
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set per month
    Delivery Time : 20 woking day
    • Product Details
    • Company Profile

    5l EVA Fully Automatic Blow Moulding Machine ABS Bottle Water

    Toggle type 2 layers double station 1 Die head Blow Molding Machine for 5L Plastic Water Kettle


    SLBU series:


    1: this machine is suitable for the production of 5L plastic hollow products, the use of curved elbow lock system, low energy consumption, the center of the lock, the lock force, speedF aster, run more smoothly.


    2: In the temperature parameter setting screen, set the set value, the upper limit, the lower limit, the lower limit, and the control state of each temperature used. The setting method: just click on the value of the set value, the upper limit, the lower limit and the lower limit of each piece of temperature, a keyboard for inputting the value will be automatically popped up, click the value to be set, and then press the enter key to confirm the value and Store, click on the control status of each temperature used, and set it to the running status. After setting it, click the “Back” button to control the main screen. Click the "warm" button and open the automatic air switches in the box one by one, so that the barrel and the die start to warm up.


    SPECIFICATIONSLBU-65
    MATERIAL PE,PP,EVA,ABS,PS
    MAX CONTAINER CAPACITYL5
    NUMBER OF DIE HEADSET1,2,3,4,6,8
    OUPUT(DRY CYCLE)PC/HR1000x2
    MACHINE DIMENSION (LxWxH )MM4000x2300x2200
    TOTAL WEIGHTTON6.5T
    CLAMPING UNIT
    CLAMPING FORCEKN65
    PLATEN OPENING STROKEMM220-520
    PLATEN SIZE(WxH)MM400x430
    MAX MOULD SIZE(WxH)MM460x430
    MOLD THICKNESSMM255-280
    EXTRUDER UNIT
    SCREW DIAMETERMM65
    SCREW L/D RATIOL/D25
    MELTING CAPACITYKG/HR70
    BARREL HEATING POWERKW15
    NUMBER OF HEATING ZONEZONE3
    EXTRUDER MOTOR RATED POWERKW15
    DIE HEAD
    NUMBER OF DIE HEATING ZONEZONE2-5
    POWER OF DIE HEATINGKW6
    CENTER DISTANCE OF DOUBLE DIEMM130
    CENTER DISTANCE OF THREE DIEMM110
    CENTER DISTANCE OF FOUR DIEMM100
    CENTER DISTANCE OF SIX DIEMM80
    MAX DIE-PIN DIAMETERMM180
    POWER
    MAX DRIVE POWERKW18
    TOTAL POWERKW50
    FAN POWER OF SCREWKW2.4
    AIR PRESSUREMPA0.6
    AIR CONSUMPTIONM3/MIN0.4
    AVERAGE ENERGY CONSUMPTIONKW18

    5l EVA Fully Automatic Blow Moulding Machine ABS Bottle Water5l EVA Fully Automatic Blow Moulding Machine ABS Bottle Water
