    8 Cavities 18kw Plastic Bottle Molding Machine Plastic Ball 4 Cavity Blow Moulding

    Ask Lasest Price
    Brand Name : SHUANGLI
    Model Number : SLBK-55
    Certification : ISO, CE
    Price : Price negotiation.
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set per month
    Delivery Time : 20 woking day
    • Product Details
    • Company Profile

    8 Cavities 18kw Plastic Bottle Molding Machine Plastic Ball 4 Cavity Blow Moulding

    Automatic Tie Bar High Speed 2 Die Head Blow Molding Machine For Plastic Light Ball


    1: the mold head mechanism: the use of the split type of the head, not channeling material, more uniform, more uniform, plating processing, not accumulating material, the material is more smooth.


    2: plasticizing system: frequency conversion motor Hardened reducer with high quality nitride barrel screw, variable frequency speed control, energy efficient and stable yield.


    3: electronic control system: the use of PLC man- machine interface, all parameters set, modify, retrieval can be seen as the operation, the system runs stable, accurate positioningIndeed.


    4: application areas: food, medicine, petroleum, chemical, chemical, automotive, tools, toys and other industries.


    5: can be equipped with automatic overflow device: supporting cutting device and pull the end device, automatic operation, save labor.


    K series extrusion blow-molding machine is the most budget-friendly product. Although after years of technological upgrades, it still occupies a position in the market with high-level performance. The mold locking system of K series


    consists of 4-guide-pillar structure and 3-plate pulling structure, which can not only hold super-wide and super-long molds but also provides enough locking force. It can produce plastic bottles of various shapes such as milk bottles, cosmetic bottles, jerry can, ocean balls and etc.
    ✓Single/Double Station
    ✓Single/Double/Triple/Quadruple..8 Head
    ✓Production Volume:2ml~2L
    ✓Multi layers: Co-Extrusion 1-4 Layers
    ✓Multi cavities: 1~8 cavities
    ✓Designed for the PE/PP/PETG/PVC/Co-Extrusion material


    SPECIFICATIONSLBK-55
    MATERIAL PE,PP,EVA,ABS,PS
    MAX CONTAINER CAPACITYL2
    NUMBER OF DIE HEADSET1,2,3,4,6
    OUPUT(DRY CYCLE)PC/HR1000x2
    MACHINE DIMENSION (LxWxH )MM3400x2200x2200
    TOTAL WEIGHTTON5T
    CLAMPING UNIT
    CLAMPING FORCEKN40
    PLATEN OPENING STROKEMM120-400
    PLATEN SIZE(WxH)MM260X330
    MAX MOULD SIZE(WxH)MM300x330
    MOLD THICKNESSMM125-220
    EXTRUDER UNIT
    SCREW DIAMETERMM55
    SCREW L/D RATIOL/D25
    MELTING CAPACITYKG/HR45
    BARREL HEATING POWERKW12
    NUMBER OF HEATING ZONEZONE3
    EXTRUDER MOTOR RATED POWERKW11
    DIE HEAD
    NUMBER OF DIE HEATING ZONEZONE2-5
    POWER OF DIE HEATINGKW6
    CENTER DISTANCE OF DOUBLE DIEMM130
    CENTER DISTANCE OF THREE DIEMM80
    CENTER DISTANCE OF FOUR DIEMM60
    CENTER DISTANCE OF SIX DIEMM60
    MAX DIE-PIN DIAMETERMM150
    POWER
    MAX DRIVE POWERKW18
    TOTAL POWERKW32
    FAN POWER OF SCREWKW2.4
    AIR PRESSUREMPA0.6
    AIR CONSUMPTIONM3/MIN0.4
    AVERAGE ENERGY CONSUMPTIONKW13

    8 Cavities 18kw Plastic Bottle Molding Machine Plastic Ball 4 Cavity Blow Moulding
