    Threaded Parts 5l PP Blow Molding Machine ABS Blowing Machine For Plastic Bottle

    Ask Lasest Price
    Brand Name : SHUANGLI
    Model Number : SLX-65
    Certification : ISO, CE
    Price : Price negotiation.
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set per month
    Delivery Time : 20 woking day
    • Product Details
    • Company Profile

    Threaded Parts 5l PP Blow Molding Machine ABS Blowing Machine For Plastic Bottle

    One Layer One Head Double Station Blow Molding Machine for Plastic Threaded Part SLX-65


    SLX series:


    1: SLX series are Shuangli company pioneered the gas -liquid combination of new type blow moulding machine, superior performance,

    stable operation, simple operation, affordable and Characteristic


    2 Visual inspection

    The machine is easy to appear damage phenomenon during the shipment, therefore, carefully inspect the machine to see whether there is damage on the appearance of the machine. If there is, please contact the Business Department and the nearest local office of our company. If you lived abroad, contact our nearest local office or agent.


    .

    SPECIFICATIONSLX-65
    MATERIAL PE,PP,EVA,ABS,PS
    MAX CONTAINER CAPACITYL5
    NUMBER OF DIE HEADSET1,2,3,4,6
    OUPUT(DRY CYCLE)PC/HR950x2
    MACHINE DIMENSION (LxWxH )MM3800x1800x2600
    TOTAL WEIGHTTON3.8T
    CLAMPING UNIT
    CLAMPING FORCEKN65
    PLATEN OPENING STROKEMM170-520
    PLATEN SIZE(WxH)MM450x400
    MAX MOULD SIZE(WxH)MM330x500
    MOLD THICKNESSMM175-250
    EXTRUDER UNIT
    SCREW DIAMETERMM65
    SCREW L/D RATIOL/D25
    MELTING CAPACITYKG/HR70
    BARREL HEATING POWERKW15
    NUMBER OF HEATING ZONEZONE3
    EXTRUDER MOTOR RATED POWERKW11(15)
    DIE HEAD
    NUMBER OF DIE HEATING ZONEZONE2-5
    POWER OF DIE HEATINGKW6
    CENTER DISTANCE OF DOUBLE DIEMM130
    CENTER DISTANCE OF THREE DIEMM80
    CENTER DISTANCE OF FOUR DIEMM60
    CENTER DISTANCE OF SIX DIEMM60
    MAX DIE-PIN DIAMETERMM260
    POWER
    MAX DRIVE POWERKW26
    TOTAL POWERKW32
    FAN POWER OF SCREWKW0.42
    AIR PRESSUREMPA0.6
    AIR CONSUMPTIONM3/MIN0.5
    AVERAGE ENERGY CONSUMPTIONKW13
